Introducing of GOR
Ready-made Unmanned Aerial System for reconnaissance and surveillance missions. The UAV is equipped with a EO and IR camera sensor along with encrypted communication tested on the battlefield.
3500 m Flight Height
40 km Tactical Range
2,5 hrs Flight Time
80x Camera Zoom
20 mbps Data Transfer Speed
30 m/s Speed
Catapult Launch and Belly Landing
Fast and reliable launch from the catapult eliminates the human factor and guarantees a successful launch. landing allows you to quickly land the plane and change your position.
Camera with Retract Mechanism
Nextvision Raptor
Resolution: 1280 x 720
Zoom: x40 + x2 digital, (total x80)
FOV:
WFOV: – 60°
NFOV: 1.5
DFOV: – °0.75°
LWIR uncooled 8-14 nm
Resolution: 1280 x 720
Zoom: x8 digital, continuous zoom
HFOV: 17.5°
W.FOV: 2.2°
Carbon Fiber Frame and Fadding
Carbon frame and carbon cladding work together as a unified structural element. The bottom of the airframe is additionally reinforced with Kevlar. This technique is used in aircraft design to ensure frame integrity.
Protected against any Electronic Warfare (EW)
The positioning system of UAV has auxiliary module which provides coordinates of UAV in GNSS denied environment.
Communication System
UAS consists of two modern data transmission modems that enable the control of UAVs and real-time image transmission. The primary modem is used for video and telemetry transmission. The backup modem is automatically activated in case of jamming of the primary one, allowing the safe leaving of the UAV from the area affected by EW equipment.
